Recirculating drying tempering small footprint low investment good grain quality

    The 5HH recirculating grain dryer is a medium & small grain drying equipment independently developed by Zhengzhou Wangu Machinery Co., Ltd. It is designed for grain planting cooperatives, family farms, small grain stations and grain purchasing points. It can continuously dehydrate high-moisture raw grains such as corn, paddy, wheat, soybean, sorghum and rapeseed in recirculation mode, reducing grain moisture to safe storage standards and minimizing losses caused by mildew and germination. Adopting drying & tempering recirculation process, grains are lifted, dried and tempered repeatedly inside the machine. Equipped with intelligent temperature control and discharge regulation system, it is suitable for small and medium batch intermittent drying, and is the preferred post-harvest drying equipment.

    The dryer consists of drying section, tempering section, grain lifting recirculation system and cooling section. Grains are lifted for repeated cycles, moisture is removed gradually in each cycle. The tempering process balances moisture inside and outside grain kernels to reduce cracking rate. Hot air exchanges heat evenly with grain layers for controllable drying. Compared with large continuous drying towers, this machine features smaller footprint, lower investment and flexible operation, suitable for batch grain processing in harvest season.

Main Features

・Batch recirculating drying: Grains circulate and lift inside the machine for multi-time tempering and dehydration, ideal for small & multi-batch grain drying. ・Compact footprint: Integrated machine structure with low foundation cost, can be placed in simple shed or open site.

・Flexible intermittent operation: Start and stop at any time, matching batch grain delivery from farmers, no need for 24h continuous production.

 ・Low breakage with low-temperature drying: Recirculating tempering process ensures gentle grain heating, low paddy cracking and grain breakage rate.

・Complete model range: Batch capacity from 10 tons to 60 tons per batch, suitable for family farms and medium & small cooperatives.

・Simplified intelligent control: PLC intelligent control system with online moisture detection to automatically adjust hot air temperature.

・Wide heat source compatibility: Compatible with biomass pellets, natural gas, coal and other hot air sources to fit local energy conditions.

・Optional mobile chassis: Mobile chassis optional for some models, convenient for site relocation.

Technical Parameters

Application Fields

    5HH recirculating grain dryer is widely used in family farms, grain cooperatives, township small grain stations and grain purchasing points. It is suitable for drying corn, paddy, wheat, soybean, sorghum, millet, rapeseed and other grain & oil crops. Indirect heat exchange with clean hot air keeps flue gas away from grains to guarantee clean finished grains. Drying parameters are adjustable for raw grains with different initial moisture. Finished grains feature uniform moisture and resist heating and mildew during storage. The equipment can be fitted with dust removal system to meet environmental tail gas emission requirements.

Packaging & Quality Assurance

    Each 5HH recirculating grain dryer is shipped in bare package. Core components including electric control cabinet, sensors and elevators are separately packed for protection for highway transportation. Reinforced components prevent collision during loading and unloading, customized packaging available upon request. All equipment is manufactured under ISO quality management system and fully inspected before delivery. Main frame and key components enjoy a 12-month warranty. Services include online technical support, on-site installation guidance, operation training and long-term spare parts supply. Minimum trial order: 1 set. Delivery cycle: 30–40 days. Payment terms: Telegraphic transfer advance payment or sight letter of credit.

    Please advise your required batch capacity, grain variety to be dried and heat source preference. We will recommend the most suitable 5HH model configuration and provide a favorable quotation.
